74F14SJX
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC INVERT SCHMITT 6CH 6-IN 14SOP
- CategoryLogic - Gates and Inverters
- Datasheet 74F14SJX Datasheet
-
ECAD Model
- Share
In Stock: 4,693
Can ship immediately
Pricing:
- 1$0.28
Quote It
Technical Details
- Series:74F
- Package:Bulk
- Part Status:Obsolete
- Logic Type:Inverter
- Number of Circuits:6
- Number of Inputs:6
- Features:Schmitt Trigger
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):-
- Current - Output High, Low:1mA, 20mA
- Logic Level - Low:1.1V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:10.5ns @ 5V, 50pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
Related Products
AND-OR-INVERT GATE, TTL, CDIP14
- 1: $0.28000
74LS125 QUAD BUS BUFFER GATESS
- 1: $0.28000
NAND GATE
- 1: $0.28000
NOR GATE, LS SERIES TTL
- 1: $0.28000
NOR GATE, LS SERIES TTL
- 1: $0.28000
IC GATE NAND 3CH 3 INP
- 1: $0.28000
IC GATE OR 4CH 2-INP 14SOP
- 1: $0.28000
IC INVERT SCHMITT 6CH 6IN 14SOIC
- 1: $0.28000
- 10: $0.24500
- 50: $0.23030
IC INVERTER OD 6CH 6-INP 14TSSOP
