HEF4073BP,652
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionAND GATE, 4000/14000/40000 SERIE
- CategoryLogic - Gates and Inverters
- Datasheet HEF4073BP,652 Datasheet
-
ECAD Model
- Share
In Stock: 16,036
Can ship immediately
Pricing:
- 1$0.29
Quote It
Technical Details
- Series:4000B
- Package:Tube
- Part Status:Active
- Logic Type:AND Gate
- Number of Circuits:3
- Number of Inputs:3
- Features:-
- Voltage - Supply:3V ~ 15V
- Current - Quiescent (Max):4 µA
- Current - Output High, Low:3mA, 3mA
- Logic Level - Low:1.5V ~ 4V
- Logic Level - High:3.5V ~ 11V
- Max Propagation Delay @ V, Max CL:40ns @ 15V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Through Hole
- Supplier Device Package:14-DIP
- Package / Case:14-DIP (0.300", 7.62mm)
