SN74HCS09PWR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE AND 4CH 2-INP 14TSSOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 3,984
Can ship immediately
Pricing:
- 1$0.83
Quote It
Technical Details
- Series:74HCS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Logic Type:AND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:Schmitt Trigger, Open Drain
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:-, 7.8mA
- Logic Level - Low:1V ~ 3V
- Logic Level - High:1.5V ~ 4.2V
- Max Propagation Delay @ V, Max CL:11ns @ 6V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-TSSOP
- Package / Case:14-TSSOP (0.173", 4.40mm Width)
