SN74AS10NSR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 3CH 3-INP 14SOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 2,136
Can ship immediately
Pricing:
- 1$1.56
- 2,000$0.6244
Quote It
Technical Details
- Series:74AS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:3
- Number of Inputs:3
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):-
- Current - Output High, Low:2mA, 20mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:4.5ns @ 5V, 50pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
