74AC11032DR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE OR 4CH 2-INP 16SOIC
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 10,784
Can ship immediately
Pricing:
- 1$0.85
Quote It
Technical Details
- Series:74AC
- Package:Bulk
- Part Status:Obsolete
- Logic Type:OR Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:3V ~ 5.5V
- Current - Quiescent (Max):4 µA
- Current - Output High, Low:24mA, 24mA
- Logic Level - Low:0.9V ~ 1.65V
- Logic Level - High:2.1V ~ 3.85V
- Max Propagation Delay @ V, Max CL:6.2ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:16-SOIC
- Package / Case:16-SOIC (0.154", 3.90mm Width)
