MC10H102L

Technical Details

• Series:10H
• Package:Tube
• Part Status:Obsolete
• Logic Type:NOR Gate
• Number of Circuits:4
• Number of Inputs:2
• Features:1 of 4 OR/NOR Output
• Voltage - Supply:-4.94V ~ -5.46V
• Current - Quiescent (Max):-

• Current - Output High, Low:50mA, 50mA
• Logic Level - Low:-1.48V
• Logic Level - High:-1.13V
• Max Propagation Delay @ V, Max CL:1.25ns @ -5.2V, -
• Operating Temperature:0°C ~ 75°C
• Mounting Type:Through Hole
• Supplier Device Package:16-CDIP
• Package / Case:16-CDIP (0.300", 7.62mm)
