74HC133D-G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 1CH 13-INP 16SO
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 1,259
Can ship immediately
Pricing:
- 1$7.99
Quote It
Technical Details
- Series:74HC
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:1
- Number of Inputs:13
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:5.2mA, 5.2mA
- Logic Level - Low:0.5V ~ 1.8V
- Logic Level - High:1.5V ~ 4.2V
- Max Propagation Delay @ V, Max CL:10ns @ 6V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:16-SO
- Package / Case:16-SOIC (0.154", 3.90mm Width)
