CD40106BCM
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionINVERTER, 4000/14000/40000 SERIE
- CategoryLogic - Gates and Inverters
- Datasheet CD40106BCM Datasheet
-
ECAD Model
- Share
In Stock: 648
Can ship immediately
Pricing:
- 1$20.27
Quote It
Technical Details
- Series:4000B
- Package:Bulk
- Part Status:Active
- Logic Type:Inverter
- Number of Circuits:6
- Number of Inputs:6
- Features:Schmitt Trigger
- Voltage - Supply:3V ~ 15V
- Current - Quiescent (Max):4 µA
- Current - Output High, Low:3.4mA, 3.4mA
- Logic Level - Low:0.7V ~ 2.1V
- Logic Level - High:4.3V ~ 12.9V
- Max Propagation Delay @ V, Max CL:160ns @ 15V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
