SN74LS136DR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE XOR OPEN 4CH 2-IN 14SOIC
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 3,009
Can ship immediately
Pricing:
- 1$0.94
- 2,500$0.34365
- 5,000$0.31995
- 12,500$0.3081
Quote It
Technical Details
- Series:74LS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Logic Type:XOR (Exclusive OR)
- Number of Circuits:4
- Number of Inputs:2
- Features:Open Collector
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Max):-
- Current - Output High, Low:-, 8mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:30ns @ 5V, 15pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
