SN74LVC1G08DCKR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSN74LVC1G08 SINGLE 2-INPUT POSIT
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 165,291
Can ship immediately
Pricing:
- 1$0.03
- 3,000$0.00976
- 6,000$0.00923
- 15,000$0.00844
Quote It
Technical Details
- Series:74LVC
- Package:Bulk
- Part Status:Active
- Logic Type:AND Gate
- Number of Circuits:1
- Number of Inputs:2
- Features:-
- Voltage - Supply:1.65V ~ 5.5V
- Current - Quiescent (Max):10 µA
- Current - Output High, Low:32mA, 32mA
- Logic Level - Low:-
- Logic Level - High:-
- Max Propagation Delay @ V, Max CL:4ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:SC-70-5
- Package / Case:5-TSSOP, SC-70-5, SOT-353
