NL17SZ00P5T5G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 1CH 2-INP SOT953
- CategoryLogic - Gates and Inverters
- Datasheet NL17SZ00P5T5G Datasheet
-
ECAD Model
- Share
In Stock: 3,832,115
Can ship immediately
Pricing:
- 1$0.06
- 8,000$0.06
Quote It
Technical Details
- Series:17SZ
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:1
- Number of Inputs:2
- Features:-
- Voltage - Supply:1.65V ~ 5.5V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:32mA, 32mA
- Logic Level - Low:-
- Logic Level - High:-
- Max Propagation Delay @ V, Max CL:4.3ns @ 5V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:SOT-953
- Package / Case:SOT-953
