74HC00PW-Q100,118
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 4CH 2-INP 14TSSOP
- CategoryLogic - Gates and Inverters
- Datasheet 74HC00PW-Q100,118 Datasheet
-
ECAD Model
- Share
In Stock: 25,155
Can ship immediately
Pricing:
- 1$0.06
- 2,500$0.06
Quote It
Technical Details
- Series:Automotive, AEC-Q100, 74HC
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):40 µA
- Current - Output High, Low:5.2mA, 5.2mA
- Logic Level - Low:0.5V ~ 1.8V
- Logic Level - High:1.5V ~ 4.2V
- Max Propagation Delay @ V, Max CL:7ns @ 6V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-TSSOP
- Package / Case:14-TSSOP (0.173", 4.40mm Width)
