74LVC08AD-Q100,118

Technical Details

• Series:74LVC
• Package:Bulk
• Part Status:Active
• Logic Type:AND Gate
• Number of Circuits:4
• Number of Inputs:2
• Features:-
• Voltage - Supply:1.2V ~ 3.6V
• Current - Quiescent (Max):40 µA

• Current - Output High, Low:24mA, 24mA
• Logic Level - Low:0.12V ~ 0.8V
• Logic Level - High:1.08V ~ 2V
• Max Propagation Delay @ V, Max CL:4.1ns @ 3.3V, 50pF
• Operating Temperature:-40°C ~ 125°C
• Mounting Type:Surface Mount
• Supplier Device Package:14-SO
• Package / Case:14-SOIC (0.154", 3.90mm Width)
