74AHCT02D,112
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NOR 4CH 2-INP 14SO
- CategoryLogic - Gates and Inverters
- Datasheet 74AHCT02D,112 Datasheet
-
ECAD Model
- Share
In Stock: 12,984
Can ship immediately
Pricing:
- 1$0.08
- 1,140$0.08
Quote It
Technical Details
- Series:74AHCT
- Package:Bulk
- Part Status:Active
- Logic Type:NOR Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:7.5ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SO
- Package / Case:14-SOIC (0.154", 3.90mm Width)
