SN74LVC1G00DSFR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSN74LVC1G00 SINGLE 2 INPUT POSIT
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 560,047
Can ship immediately
Pricing:
- 1$0.09
- 5,000$0.09
- 10,000$0.08437
- 25,000$0.07762
Quote It
Technical Details
- Series:74LVC
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:1
- Number of Inputs:2
- Features:-
- Voltage - Supply:1.65V ~ 5.5V
- Current - Quiescent (Max):10 µA
- Current - Output High, Low:32mA, 32mA
- Logic Level - Low:0.7V ~ 0.8V
- Logic Level - High:1.7V ~ 2V
- Max Propagation Delay @ V, Max CL:4.3ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:6-SON (1x1)
- Package / Case:6-XFDFN
