XC7SH14GV,125
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionNOW NEXPERIA XC7SH14GV - INVERTE
- CategoryLogic - Gates and Inverters
- Datasheet XC7SH14GV,125 Datasheet
-
ECAD Model
- Share
In Stock: 66,131
Can ship immediately
Pricing:
- 1$0.09
- 3,000$0.027
- 6,000$0.02536
- 15,000$0.02373
- 30,000$0.02176
- 75,000$0.02095
Quote It
Technical Details
- Series:7SH
- Package:Bulk
- Part Status:Active
- Logic Type:Inverter
- Number of Circuits:1
- Number of Inputs:1
- Features:Schmitt Trigger
- Voltage - Supply:2V ~ 5.5V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.9V ~ 1.65V
- Logic Level - High:2.2V ~ 3.85V
- Max Propagation Delay @ V, Max CL:10.6ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:SC-74A
- Package / Case:SC-74A, SOT-753
