74AXP1G09GXH
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE AND OD 1CH 2-INP 5X2SON
- CategoryLogic - Gates and Inverters
- Datasheet 74AXP1G09GXH Datasheet
-
ECAD Model
- Share
In Stock: 10,155
Can ship immediately
Pricing:
- 1$0.09
- 10,000$0.09
Quote It
Technical Details
- Series:74AXP
- Package:Bulk
- Part Status:Active
- Logic Type:AND Gate
- Number of Circuits:1
- Number of Inputs:2
- Features:Open Drain
- Voltage - Supply:0.7V ~ 2.75V
- Current - Quiescent (Max):600 nA
- Current - Output High, Low:-, 8mA
- Logic Level - Low:-
- Logic Level - High:-
- Max Propagation Delay @ V, Max CL:4.1ns @ 2.5V, 5pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:5-X2SON (0.80x0.80)
- Package / Case:4-XFDFN Exposed Pad
