N74F04D,602
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC INVERTER 6CH 6-INP 14SO
- CategoryLogic - Gates and Inverters
- Datasheet N74F04D,602 Datasheet
-
ECAD Model
- Share
In Stock: 51,612
Can ship immediately
Pricing:
- 1$0.1
Quote It
Technical Details
- Series:74F
- Package:Bulk
- Part Status:Obsolete
- Logic Type:Inverter
- Number of Circuits:6
- Number of Inputs:6
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):-
- Current - Output High, Low:1mA, 20mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:5ns @ 5V, 50pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SO
- Package / Case:14-SOIC (0.154", 3.90mm Width)
