SN74LV86ADBR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE XOR 4CH 2-INP 14SSOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 109,897
Can ship immediately
Pricing:
- 1$0.11
- 2,000$0.11
- 6,000$0.10333
- 10,000$0.09667
Quote It
Technical Details
- Series:74LV
- Package:Bulk
- Part Status:Active
- Logic Type:XOR (Exclusive OR)
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 5.5V
- Current - Quiescent (Max):20 µA
- Current - Output High, Low:12mA, 12mA
- Logic Level - Low:0.5V
- Logic Level - High:1.5V
- Max Propagation Delay @ V, Max CL:8.8ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SSOP
- Package / Case:14-SSOP (0.209", 5.30mm Width)
