NLVVHC1GT02DFT2G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NOR 1CH 2-INP SC88A
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 114,184
Can ship immediately
Pricing:
- 1$0.13
Quote It
Technical Details
- Series:74VHC
- Package:Bulk
- Part Status:Active
- Logic Type:NOR Gate
- Number of Circuits:1
- Number of Inputs:2
- Features:-
- Voltage - Supply:3V ~ 5.5V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.53V ~ 0.8V
- Logic Level - High:1.4V ~ 2V
- Max Propagation Delay @ V, Max CL:7.7ns @ 5V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:SC-88A (SC-70-5/SOT-353)
- Package / Case:5-TSSOP, SC-70-5, SOT-353
