SN74LVC00APWE4
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 4CH 2-INP 14TSSOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 1,715
Can ship immediately
Pricing:
- 1$0.14
- 3,060$0.14
Quote It
Technical Details
- Series:74LVC
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:1.65V ~ 3.6V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:24mA, 24mA
- Logic Level - Low:0.7V ~ 0.8V
- Logic Level - High:1.7V ~ 2V
- Max Propagation Delay @ V, Max CL:4.1ns @ 3.3V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-TSSOP
- Package / Case:14-TSSOP (0.173", 4.40mm Width)
