SN74HC10NS
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 3CH 3-INP 14SOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 2,848
Can ship immediately
Pricing:
- 1$0.15
Quote It
Technical Details
- Series:74HC
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:3
- Number of Inputs:3
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:5.2mA, 5.2mA
- Logic Level - Low:0.5V ~ 1.8V
- Logic Level - High:1.5V ~ 4.2V
- Max Propagation Delay @ V, Max CL:16ns @ 6V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
