NC7SZ27L6X
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NOR 1CH 3-INP 6MICROPAK
- CategoryLogic - Gates and Inverters
- Datasheet NC7SZ27L6X Datasheet
-
ECAD Model
- Share
In Stock: 179,394
Can ship immediately
Pricing:
- 1$0.18
- 5,000$0.15338
Quote It
Technical Details
- Series:7SZ
- Package:Bulk
- Part Status:Active
- Logic Type:NOR Gate
- Number of Circuits:1
- Number of Inputs:3
- Features:-
- Voltage - Supply:1.65V ~ 5.5V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:32mA, 32mA
- Logic Level - Low:-
- Logic Level - High:-
- Max Propagation Delay @ V, Max CL:5.5ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:6-MicroPak
- Package / Case:6-UFDFN
