MC74VHC132DR2G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 4CH 2-INP 14SOIC
- CategoryLogic - Gates and Inverters
- Datasheet MC74VHC132DR2G Datasheet
-
ECAD Model
- Share
In Stock: 6,329
Can ship immediately
Pricing:
- 1$0.18
- 2,500$0.15728
Quote It
Technical Details
- Series:74VHC
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:Schmitt Trigger
- Voltage - Supply:2V ~ 5.5V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.9V ~ 1.65V
- Logic Level - High:2.2V ~ 3.85V
- Max Propagation Delay @ V, Max CL:9.7ns @ 5V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
