MC74LVX132DTG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 4CH 2-INP 14TSSOP
- CategoryLogic - Gates and Inverters
- Datasheet MC74LVX132DTG Datasheet
-
ECAD Model
- Share
In Stock: 23,266
Can ship immediately
Pricing:
- 1$0.19
- 1,440$0.18903
Quote It
Technical Details
- Series:74LVX
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 3.6V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:4mA, 4mA
- Logic Level - Low:0.3V ~ 1V
- Logic Level - High:1.6V ~ 2.6V
- Max Propagation Delay @ V, Max CL:15.4ns @ 3.3V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-TSSOP
- Package / Case:14-TSSOP (0.173", 4.40mm Width)
