SN74F10DR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 3CH 3-INP 14SOIC
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 5,174
Can ship immediately
Pricing:
- 1$0.2
- 2,500$0.2
- 5,000$0.1871
- 12,500$0.17419
Quote It
Technical Details
- Series:74F
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:3
- Number of Inputs:3
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):-
- Current - Output High, Low:1mA, 20mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:5ns @ 5V, 50pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
