CD4093BQM96G4Q1
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 4CH 2-INP 14SOIC
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 1,020,656
Can ship immediately
Pricing:
- 1$0.22
- 2,500$0.22
- 5,000$0.20581
- 12,500$0.19161
Quote It
Technical Details
- Series:Automotive, AEC-Q100, 4000B
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:3V ~ 18V
- Current - Quiescent (Max):4 µA
- Current - Output High, Low:3.4mA, 3.4mA
- Logic Level - Low:0.9V ~ 4V
- Logic Level - High:3.6V ~ 10.8V
- Max Propagation Delay @ V, Max CL:130ns @ 15V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
