MM74HCT05M
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE XNOR 4CH 2-INP 14SOIC
- CategoryLogic - Gates and Inverters
- Datasheet MM74HCT05M Datasheet
-
ECAD Model
- Share
In Stock: 281,649
Can ship immediately
Pricing:
- 1$0.23
- 10$0.19568
- 100$0.14614
- 500$0.11482
- 1,000$0.08873
Quote It
Technical Details
- Series:74HCT
- Package:Bulk
- Part Status:Active
- Logic Type:XNOR (Exclusive NOR)
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:5.2mA, 5.2mA
- Logic Level - Low:0.3V ~ 1.2V
- Logic Level - High:1.5V ~ 4.2V
- Max Propagation Delay @ V, Max CL:20ns @ 6V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
