SN74LS05DBR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC INVERTER OPEN 6CH 6-IN 14SSOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 49,798
Can ship immediately
Pricing:
- 1$0.4
- 2,000$0.37735
- 6,000$0.35849
- 10,000$0.34501
Quote It
Technical Details
- Series:74LS
- Package:Bulk
- Part Status:Active
- Logic Type:Inverter
- Number of Circuits:6
- Number of Inputs:6
- Features:Open Collector
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Max):-
- Current - Output High, Low:-, 8mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:32ns @ 5V, 15pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SSOP
- Package / Case:14-SSOP (0.209", 5.30mm Width)
