SN74ALS804AN
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 6CH 2-INP 20DIP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 240
Can ship immediately
Pricing:
- 1$6.53
- 20$5.8982
- 40$5.62417
- 100$4.8833
- 500$4.25234
- 1,000$3.70365
- 2,500$3.56648
Quote It
Technical Details
- Series:74ALS
- Package:Tube
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:6
- Number of Inputs:2
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):-
- Current - Output High, Low:15mA, 24mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:8ns @ 5V, 50pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Through Hole
- Supplier Device Package:20-PDIP
- Package / Case:20-DIP (0.300", 7.62mm)
