CD74HC20MG4

Texas Instruments
  • Lifecycle status Active
  • RoHS RoHS Compliant
  • DescriptionIC GATE NAND 2CH 4-INP 14SOIC
  • CategoryLogic - Gates and Inverters
  • ECAD Model
  • Share
In Stock: 130

Can ship immediately

Pricing:
  • 1$0.2685
  • 1,700$0.2533

Quote It

Technical Details

  • Series:74HC
  • Package:Tube
  • Part Status:Active
  • Logic Type:NAND Gate
  • Number of Circuits:2
  • Number of Inputs:4
  • Features:-
  • Voltage - Supply:2V ~ 6V
  • Current - Quiescent (Max):2 µA



  • Current - Output High, Low:5.2mA, 5.2mA
  • Logic Level - Low:0.5V ~ 1.8V
  • Logic Level - High:1.5V ~ 4.2V
  • Max Propagation Delay @ V, Max CL:17ns @ 6V, 50pF
  • Operating Temperature:-55°C ~ 125°C
  • Mounting Type:Surface Mount
  • Supplier Device Package:14-SOIC
  • Package / Case:14-SOIC (0.154", 3.90mm Width)
