SN74S09NSR
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE AND OP COL 4CH 2IN 14SOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$2.0428
- 2,000$1.92717
Quote It
Technical Details
- Series:74S
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Logic Type:AND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:Open Collector
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Max):32 mA
- Current - Output High, Low:-, 20mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:9ns @ 5V, 50pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
