SN54AC00VTD2
Texas Instruments- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 4CH 2-INP DIE
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$465.569
- 10$465.569
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):-
- Current - Output High, Low:-
- Logic Level - Low:-
- Logic Level - High:-
- Max Propagation Delay @ V, Max CL:-
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:-
- Supplier Device Package:Die
- Package / Case:Die
