74VCX132BQX
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 4CH 2-INP 14DQFN
- CategoryLogic - Gates and Inverters
- Datasheet 74VCX132BQX Datasheet
-
ECAD Model
- Share
In Stock: 193
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:74VCX
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Logic Type:NAND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:Schmitt Trigger
- Voltage - Supply:1.4V ~ 3.6V
- Current - Quiescent (Max):20 µA
- Current - Output High, Low:24mA, 24mA
- Logic Level - Low:0.2V ~ 0.8V
- Logic Level - High:1.2V ~ 2.2V
- Max Propagation Delay @ V, Max CL:3.3ns @ 3.3V, 30pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-DQFN (3x2.5)
- Package / Case:14-VFQFN Exposed Pad
