74LVQ08SJ
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE AND 4CH 2-INP 14SOP
- CategoryLogic - Gates and Inverters
- Datasheet 74LVQ08SJ Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:74LVQ
- Package:Tube
- Part Status:Obsolete
- Logic Type:AND Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 3.6V
- Current - Quiescent (Max):2 µA
- Current - Output High, Low:12mA, 12mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:9.5ns @ 3.3V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
