MM74C914MX
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC INVERT SCHMITT 6CH 6IN 14SOIC
- CategoryLogic - Gates and Inverters
- Datasheet MM74C914MX Datasheet
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:74C
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Logic Type:Inverter
- Number of Circuits:6
- Number of Inputs:6
- Features:Schmitt Trigger
- Voltage - Supply:3V ~ 15V
- Current - Quiescent (Max):-
- Current - Output High, Low:8mA, 8mA
- Logic Level - Low:0.7V ~ 2.1V
- Logic Level - High:4.3V ~ 12.9V
- Max Propagation Delay @ V, Max CL:200ns @ 10V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
