HCF4012BEY

Technical Details

• Series:4000B
• Package:Tube
• Part Status:Obsolete
• Logic Type:NAND Gate
• Number of Circuits:2
• Number of Inputs:4
• Features:-
• Voltage - Supply:3V ~ 20V
• Current - Quiescent (Max):5 µA

• Current - Output High, Low:6.8mA, 6.8mA
• Logic Level - Low:1.5V ~ 4V
• Logic Level - High:3.5V ~ 11V
• Max Propagation Delay @ V, Max CL:90ns @ 15V, 50pF
• Operating Temperature:-55°C ~ 125°C
• Mounting Type:Through Hole
• Supplier Device Package:14-DIP
• Package / Case:14-DIP (0.300", 7.62mm)
