CD4072BPWRE4
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE OR 2CH 4-INP 14TSSOP
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 170
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:4000B
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Logic Type:OR Gate
- Number of Circuits:2
- Number of Inputs:4
- Features:-
- Voltage - Supply:3V ~ 18V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:3.4mA, 3.4mA
- Logic Level - Low:1.5V ~ 4V
- Logic Level - High:3.5V ~ 11V
- Max Propagation Delay @ V, Max CL:90ns @ 15V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-TSSOP
- Package / Case:14-TSSOP (0.173", 4.40mm Width)
