74VHC02TTR

Technical Details

• Series:74VHC
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Logic Type:NOR Gate
• Number of Circuits:4
• Number of Inputs:2
• Features:-
• Voltage - Supply:2V ~ 5.5V
• Current - Quiescent (Max):2 µA

• Current - Output High, Low:8mA, 8mA
• Logic Level - Low:0.5V
• Logic Level - High:1.5V
• Max Propagation Delay @ V, Max CL:7.5ns @ 5V, 50pF
• Operating Temperature:-55°C ~ 125°C
• Mounting Type:Surface Mount
• Supplier Device Package:14-TSSOP
• Package / Case:14-TSSOP (0.173", 4.40mm Width)
