NC7ST32M5X_F065
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE OR 1CH 2-INP SOT23-5
- CategoryLogic - Gates and Inverters
- Datasheet NC7ST32M5X_F065 Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:7ST
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Logic Type:OR Gate
- Number of Circuits:1
- Number of Inputs:2
- Features:-
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:2mA, 2mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:26ns @ 5.5V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:SOT-23-5
- Package / Case:SC-74A, SOT-753
