ADS7815U
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC ADC 16BIT SAR 28SOIC
- CategoryData Acquisition - Analog to Digital Converters (ADC)
-
ECAD Model
- Share
In Stock: 281
Can ship immediately
Pricing:
- 1$43.64
- 20$40.7138
- 40$39.00709
- 100$35.35033
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:16
- Sampling Rate (Per Second):250k
- Number of Inputs:1
- Input Type:Single Ended
- Data Interface:Parallel
- Configuration:S/H-ADC
- Ratio - S/H:ADC:1:1
- Number of A/D Converters:1
- Architecture:SAR
- Reference Type:External, Internal
- Voltage - Supply, Analog:±5V
- Voltage - Supply, Digital:5V
- Features:-
- Operating Temperature:-25°C ~ 85°C
- Package / Case:28-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:28-SOIC
- Mounting Type:Surface Mount
