ADS7861E
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC ADC 12BIT SAR 24SSOP/QSOP
- CategoryData Acquisition - Analog to Digital Converters (ADC)
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$12.52
- 10$11.51077
- 50$11.03355
- 100$9.72144
- 500$8.64789
- 1,000$7.93219
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Sampling Rate (Per Second):500k
- Number of Inputs:4
- Input Type:Differential
- Data Interface:SPI
- Configuration:MUX-S/H-ADC
- Ratio - S/H:ADC:1:1
- Number of A/D Converters:2
- Architecture:SAR
- Reference Type:External, Internal
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:5V
- Features:Selectable Address, Simultaneous Sampling
- Operating Temperature:-40°C ~ 125°C
- Package / Case:24-SSOP (0.154", 3.90mm Width)
- Supplier Device Package:24-SSOP/QSOP
- Mounting Type:Surface Mount
