CS5525-ASZR
Cirrus Logic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC ADC 16BIT SIGMA-DELTA 20SSOP
- CategoryData Acquisition - Analog to Digital Converters (ADC)
- Datasheet CS5525-ASZR Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$8.12
- 2,000$8.12
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Number of Bits:16
- Sampling Rate (Per Second):616
- Number of Inputs:1
- Input Type:Differential
- Data Interface:SPI
- Configuration:ADC
- Ratio - S/H:ADC:-
- Number of A/D Converters:1
- Architecture:Sigma-Delta
- Reference Type:External
- Voltage - Supply, Analog:5V
- Voltage - Supply, Digital:3V, 5V
- Features:PGA, Selectable Address
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-SSOP (0.209", 5.30mm Width)
- Supplier Device Package:20-SSOP
- Mounting Type:Surface Mount
