ICL7109IPL+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC ADC 12BIT DUAL SLOPE 40DIP
- CategoryData Acquisition - Analog to Digital Converters (ADC)
- Datasheet ICL7109IPL+ Datasheet
-
ECAD Model
- Share
In Stock: 404
Can ship immediately
Pricing:
- 1$16.354
- 30$13.84356
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:12
- Sampling Rate (Per Second):30
- Number of Inputs:1
- Input Type:Differential
- Data Interface:Parallel
- Configuration:ADC
- Ratio - S/H:ADC:-
- Number of A/D Converters:1
- Architecture:Dual Slope
- Reference Type:External
- Voltage - Supply, Analog:±5V
- Voltage - Supply, Digital:±5V
- Features:-
- Operating Temperature:-20°C ~ 85°C
- Package / Case:40-DIP (0.600", 15.24mm)
- Supplier Device Package:40-PDIP
- Mounting Type:Through Hole
