PFB0612EE-E
Delta Electronics / Fans- Lifecycle status Active
- RoHS RoHS Compliant
- Description60X60X38MM 12V DC FAN W/PWM CONT
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
- 1$36.46
Quote It
Technical Details
- Series:PFB
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 60mm L x 60mm H
- Width:38.00mm
- Air Flow:77.0 CFM (2.16m³/min)
- Static Pressure:7.310 in H2O (1820.8 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
- Noise:68.6dB(A)
- Power (Watts):42 W
- RPM:25500 RPM
- Termination:4 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, cURus, TUV
- Weight:-
