AFB0612HB-R00

Technical Details

• Series:AFB
• Package:Bulk
• Part Status:Active
• Voltage - Rated:12VDC
• Size / Dimension:Square - 60mm L x 60mm H
• Width:15.00mm
• Air Flow:15.4 CFM (0.431m³/min)
• Static Pressure:0.155 in H2O (38.6 Pa)
• Bearing Type:Ball
• Fan Type:Tubeaxial

• Features:Locked Rotor Sensor
• Noise:32.0dB(A)
• Power (Watts):1.2 W
• RPM:4000 RPM
• Termination:3 Wire Leads
• Ingress Protection:-
• Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
• Approval Agency:CE, CSA, UL, VDE
• Weight:0.098 lb (44.45 g)
