109P0412M601
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 40X20MM 12VDC TACH
- CategoryDC Brushless Fans (BLDC)
- Datasheet 109P0412M601 Datasheet
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
- 1$8.36257
- 140$7.63886
Quote It
Technical Details
- Series:San Ace 40
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 40mm L x 40mm H
- Width:20.00mm
- Air Flow:4.8 CFM (0.134m³/min)
- Static Pressure:0.106 in H2O (26.4 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Speed Sensor (Tach)
- Noise:24.0dB(A)
- Power (Watts):720 mW
- RPM:5000 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.101 lb (45.81 g)
