DC0402012L2B-2T0
Wakefield-Vette
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 12VDC 40X20MM 2WIRES
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$8.67673
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 40mm L x 40mm H
- Width:20.00mm
- Air Flow:9.4 CFM (0.263m³/min)
- Static Pressure:0.350 in H2O (87.2 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection
- Noise:33.0dB(A)
- Power (Watts):960 mW
- RPM:8000 RPM
- Termination:2 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, cURus, TUV
- Weight:0.045 lb (20.41 g)
