AFB0624EH-ABF00
Delta Electronics / Fans- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 60X60X25MM
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
- 1$8.82
Quote It
Technical Details
- Series:AFB
- Package:Bulk
- Part Status:Active
- Voltage - Rated:24VDC
- Size / Dimension:Square - 60mm L x 60mm H
- Width:25.40mm
- Air Flow:38.4 CFM (1.08m³/min)
- Static Pressure:0.544 in H2O (135.5 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection, Speed Sensor (Tach)
- Noise:46.5dB(A)
- Power (Watts):5.76 W
- RPM:6800 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, CSA, UL, VDE
- Weight:0.176 lb (80.00 g)
