EE80252BX-000U-G99

Technical Details

• Series:EE
• Package:Bulk
• Part Status:Active
• Voltage - Rated:24VDC
• Size / Dimension:Square - 80mm L x 80mm H
• Width:25.00mm
• Air Flow:45.0 CFM (1.26m³/min)
• Static Pressure:0.230 in H2O (57.3 Pa)
• Bearing Type:Ball
• Fan Type:Tubeaxial

• Features:Auto Restart, Speed Sensor (Tach)
• Noise:38.0dB(A)
• Power (Watts):1.9 W
• RPM:3600 RPM
• Termination:3 Wire Leads
• Ingress Protection:-
• Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
• Approval Agency:CE, CUR, TUV, UL
• Weight:0.196 lb (88.9 g)
